KIP 7980

New Integrated CIS Colour Scanner KIP 720
14 D’ / A1 size prints per minute – 5,040 Sq./Ft. per hour
New 2 or 4 Roll configuration
Top stacking
Small footprint design
KIP System K Software

Get in touch

Share

Interested to see all features and options and build your very own KIP 7980?

Click here to configure your device

Features

KIP 7980 Multi-Function Systems

KIP 7980 MFP systems feature an integrated CIS scanner and innovative top stacking to fit where you need it – in tight spaces or against the wall for easy access to all system features. Increase copy, scan and print workflow efficiency with the powerful KIP smart multi-touchscreen for intuitive feature selection and easy operation. Zoom, rotate and pan vivid on-screen previews for eight point Area of Interest editing and printing.

Specifications & Downloads

Specifications

General
Description	Monochrome wide format print/copy/scan with colour scanner
Type	Electrophotography (LED) with organic photoconductor (OPC) and closed toner
Speed A1 size per minute	14
Warm up time	Less than 2 minutes from standby
Configurations	Printer / MFP
Roll options	2 or 4 Roll
Output delivery	Top / rear
Electrical requirements	220 – 240 V, 50/60 Hz, 16 A
Power consumption	2,700 W (printing), 1,100 W (standby)
Printer
Print resolution	600 x 2,400 dpi
Paper capacity	2 or 4 roll
Output sizes width	297 mm – 914 mm
Output sizes length	6 m (standard), 150 m based on media validation
Paper weight (roll media)	Bond-plain 64–90 gsm, vellum-translucent-tracing 80 gsm, film 75 gsm
Media types	Bond, vellum, film
Controller
Controller type	KIP System K Controller with Windows® 7 embedded
Memory	2GB DDR3 standard - upgradable to 4 GB
Hard drive minimum	320 GB - unlimited upgrade
Supported file type	DWF, PDF, PDF-A, HPGL 1/2, HP-RTL, Calcomp 906/907, CALS Group 4, TIFF Group 4, CIT/TG4, Grayscale TIFF, TIFF Packbits, PNG, JPEG
Scanner KIP 720
Scanner Type	C.I.S. with KIP RTT Technology
Scan Resolution	600 x 600 dpi optical resolution
Scan Speed	Up to 203 mm per second (B&W) and up to 66 mm per second (Color)
Scan Format	TIFF, Multipage TIFF, PDF, PDF-A, Multipage PDF, DWF, Multipage DWF, JPEG, CALS
Scan Destination	Local USB (Removable Media), Unlimited IPS Mailboxes (Local), Unlimited FTP, Unlimited SMB
Original Size	Width 279 - 914 mm
Original Thickness	Up to 1.6 mm thick
Interface	USB 2.0
Dimensions	1,092 mm x 406 mm x 170 mm
Weight	25 Kg
Electrical	100-240 V AC 50/60 Hz
Power Consumption	<50 W

The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that all specifications mentioned will be error-free.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Get the product brochure now to have all information at hand.

KIP 7980 brochure
