KIP 7970

14 D’ / A1 size prints per minute – 5,040 Sq./Ft. per hour
New 2 or 4 Roll configuration
Top stacking
Small footprint design
KIP System K Software

Get in touch

Share

Interested to see all features and options and build your very own KIP 7970?

Click here to configure your device

Features

KIP 7970 Print Systems

The KIP 7970 network print system with top stacking meets the tough workflow demands of digital print environments. The Perfect View adjustable KIP smart multi-touchscreen is ideal for selecting multiple files from a variety of network resources for print set submission and managing system features.

Specifications & Downloads

Specifications

General
Description	Monochrome wide format print/copy/scan with colour scanner
Type	Electrophotography (LED) with organic photoconductor (OPC) and closed toner
Speed A1 size per minute	14
Warm up time	Less than 2 minutes from standby
Configurations	Printer / MFP
Roll options	2 or 4 Roll
Output delivery	Top / rear
Electrical requirements	220 – 240 V, 50/60 Hz, 16 A
Power consumption	2,700 W (printing), 1,100 W (standby)
Printer
Print resolution	600 x 2,400 dpi
Paper capacity	2 or 4 roll
Output sizes width	297 mm – 914 mm
Output sizes length	6 m (standard), 150 m based on media validation
Paper weight (roll media)	Bond-plain 64–90 gsm, vellum-translucent-tracing 80 gsm, film 75 gsm
Media types	Bond, vellum, film
Controller
Controller type	KIP System K Controller with Windows® 7 embedded
Memory	2GB DDR3 standard - upgradable to 4 GB
Hard drive minimum	320 GB - unlimited upgrade
Supported file type	DWF, PDF, PDF-A, HPGL 1/2, HP-RTL, Calcomp 906/907, CALS Group 4, TIFF Group 4, CIT/TG4, Grayscale TIFF, TIFF Packbits, PNG, JPEG

The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that all specifications mentioned will be error-free.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Get the product brochure now to have all information at hand.

KIP 7970 brochure
