KIP 7990

Production MFP design with KIP 2300 CCD Scanner
14 D’ / A1 size prints per minute – 5,040 Sq./Ft. per hour
New 2 or 4 Roll configuration
Top stacking
KIP System K Software

Share

Interested to see all features and options and build your very own KIP 7990?

Click here to configure your device

Features

KIP 7990 Multi-Function Production Systems

The KIP 7990 Production MFP systems address the current reality of demanding print runs and compressed delivery times coupled with the highest quality expectations. Operators will enjoy superior pre-flight and print submission productivity using the professional applications within the KIP System K Print Management Suite. The KIP 2300 CCD production scanner sets a uniquely high standard for colour scanning speed, face up/face down/thick media document feeding versatility and digital imaging quality.

Specifications & Downloads

Specifications

General
Description	Monochrome wide format print/copy/scan with colour scanner
Type	Electrophotography (LED) with organic photoconductor (OPC) and closed toner
Speed A1 size per minute	14
Warm up time	Less than 2 minutes from standby
Configurations	Printer / MFP
Roll options	2 or 4 Roll
Output delivery	Top / rear
Electrical requirements	220 – 240 V, 50/60 Hz, 16 A
Power consumption	2,700 W (printing), 1,100 W (standby)
Printer
Print resolution	600 x 2,400 dpi
Paper capacity	2 or 4 roll
Output sizes width	297 mm – 914 mm
Output sizes length	6 m (standard), 150 m based on media validation
Paper weight (roll media)	Bond-plain 64–90 gsm, vellum-translucent-tracing 80 gsm, film 75 gsm
Media types	Bond, vellum, film
Controller
Controller type	KIP System K Controller with Windows® 7 embedded
Memory	2GB DDR3 standard - upgradable to 4 GB
Hard drive minimum	320 GB - unlimited upgrade
Supported file type	DWF, PDF, PDF-A, HPGL 1/2, HP-RTL, Calcomp 906/907, CALS Group 4, TIFF Group 4, CIT/TG4, Grayscale TIFF, TIFF Packbits, PNG, JPEG
Scanner KIP 2300
Scanner Type	C.C.D. with KIP Tru-Speed Technology and KIP RTT Technology
Scan Resolution	600 x 600 dpi optical resolution
Scan Speed	Up to 18 m per minute (Mono) and up to 9 m per minute (Color)
Scan Formats	TIFF, Multipage TIFF, PDF, PDF-A, Multipage PDF, DWF, Multipage DWF, JPEG, CALS
Scan Destination	Local USB (Removable Media), Unlimited IPS Mailboxes (Local), Unlimited FTP, Unlimited SMB
Original Size	Width/Length Originals Up to 1,066 mm - 914 mm Scan width
Original Thickness	Up to 16 mm Automatic thickness detection
Original	Face Up/Face Down Both - Dual Original Feed Tables
Interface	USB 2.0, KIP Tru•Speed Technology (2.3GB per sec data transfer)
Dimensions	1,399 mm W, 480 mm D, 310 mm H
Weight	73 kg
Electrical	100-240V AC 50/60 Hz
Power Consumption	<120 W

The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that all specifications mentioned will be error-free.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Get the product brochure now to have all information at hand.

KIP 7990 brochure
