KIP 2300

Rigid/thick document support up to 16 mm thickness
User-selectable scan modes: face-up or face-down scanning!
High-speed data transfer with KIP Tru-Speed technology: mono-scan speeds up to 18 m per minute, colour-scan speeds up to 9 m per minute
Automatic imaging camera and white-balance calibration
Distinctive white LED original illumination system for consistent image capture
Independent Tri-Linear CCD Cameras with an advanced single lens design
Instant on: no warm-up necessary
Automatic image width detection in automatic mode
Flexible colour software solutions and total colour workflow integration
Energy Star-compliant
Integration with KIP Wide Format printers

Get in touch

Share

Features

KIP 2300

The KIP 2300 high-productivity scanner sets a uniquely high standard for speed, quality and flexibility in a digital image capture system. Best-in-class productivity is achieved via new KIP Tru-Speed Technology for high-speed data processing with no delays. Outstanding image quality is delivered through the innovative use of bright white LED light sources for illumination and 600 x 600 dpi image capture resolution. The KIP 2300 monochrome & colour scanner provides demanding users with the highest image quality, versatility and productivity.

Specifications & Downloads

Specifications

Model:	KIP 2300 image scanner
Type:	C.C.D. with KIP True • Speed Technology and KIP RTT Technology
Scan resolution	600 x 600 dpi optical resolution
Scan Speed	Up to 18 m per minute (Mono) Up to 9 m per minute (Colour)
Scan Format	TIFF, Multipage TIFF, PDF, PDF-A, Multipage PDF, DWF, Multipage DWF, JPEG, CALS
Scan Destinations	Local USB (Removable Media) Unlimited IPS Mailboxes (Local) Unlimited FTP Unlimited SMB
Original Size Width	Originals Up to 1,066 mm - 914 mm Scan width
Original Thickness	Up to 16 mm Automatic thickness detection
Original Face Up/Face Down	Both - Dual Original Feed Tables
Interface	USB 2.0, KIP Tru • Speed Technology (2.3 GB per sec data transfer)
Dimensions	1,399 mm W, 480 mm D, 310 mm H
Weight	73 Kg
Electrical	100-240V AC 50/60 Hz
Power Consumption	< 120 W
Minimum PC Requirements	Quad Core Processor (Intel i5 or higher) Windows XP / 7 (32- or 64-Bit) 8 GB RAM with 64-Bit or 3 GB RAM 32-Bit 1 TB Hard Drive (Example: 100 colour or 300 mono A1 images in a large set would require up to 5 GB) 1 GB RJ45 Lan Port (Wireless is not recommended due to file transfers during copy process) DVD/CD Optical Drive One available USB 2.0 ports or higher for KIP Colour Advanced/Pro (scanner connection) One PCI-e port (for use with the KIP Tru•Speed card (HIL) One available USB 2.0 ports or higher for KIP RIP (product code connection) 20” flat panel monitor (with VESA - 75 or 100 patterns for use with the KIP Scanner Stand) USB Keyboard & Mouse

The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
Some of the product illustrations contain optional accessories.
Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
Konica Minolta does not warrant that all specifications mentioned will be error-free.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Get the product brochure now to have all information at hand.

KIP 2300 brochure
