EFI H1625LED

  • Hybrid wide format printer - Printing on flexible roll-to-roll media as well as on rigid materials for premium margin applications
  • H1625 LED 8-Level greyscale variable drop technology for photographic image quality
  • Digital Advantage - Ideal for lucrative short- and medium-run WIDE FORMAT printing
  • CMYK + double white printing - For more vivid colours and beautiful 3-layer white applications
  • Productivity in different quality modes for high quality and high speed wide format applications
Konica Minolta efi h 1625led professional printer
Konica Minolta efi h 1625led professional printer
Konica Minolta efi h 1625led professional printer
Konica Minolta efi h 1625led professional printer

Features

Features

EFI H1625LED

As a wide format hybrid printer with UV ink technology, the EFI H1625 LED combines the advantages of wide-format role-to-role and flatbed printing. It produces high quality images in widths up to 1.6 meters, is extremely versatile and allows printing on flexible media as well as rigid materials. The H1625 LED is ideal for premium rigid and soft-signage applications. Using true eight-level variable drop greyscale technology and LED UV cured inks, it delivers stunning images and durable prints across the widest variety of substrates. Environmentally friendly, it features optimized ink usage, produces minimal VOC levels compared to solvent-based printers and less heat than latex printers, lowering your energy costs.Whether you are a Commercial Printer, focus on Point-of-Purchase and signage applications, cater to the graphics market, or run eco-solvent or latex printing equipment – even for in-house print shops the H1625 LED is the alternative to upgrade or expand, driving diversification and profitability.

Konica Minolta efi h 1625led professional printer

Specifications & Downloads

Specifications & Downloads
System Configurations
Print technology UV ink technology
Up to 8 levels of variable-drop grayscale
Curing technology Dynamic curing LED UV lamps
Colours CMYK plus 2 white channels
Weight 1,235 kg including tables and rollers
Dimensions (wxdxh) with one set of tables 348 cm x 234 cm x 160 cm
Depth without table/rollers 87 cm without tables or rollers
145 cm without tables
Media width Up to 165 cm (65’’) wide
Image width Up to 162.6 cm (64’’) full-bleed printing
Media thickness Up to 5.08 cm thickness
Media type Handles flexible and rigid substrates
Media weight (rigid & roll) 45.4 kg
Max. roll diameter 22.9 cm (9”)
File formats All popular desktop files formats,
including PostScript®3™, EPS, TIFF, PDF and RGB/CMYK
Environmental Considerations
Temperature 18° C to 26.7° C
Humidity 20 % to 80 % (noncondensing)
Electrical 208 – 240 VAC, single phase, 50/60 Hz,
30 Amps
Productivity
Ultra quality mode 7.4 m2/hr
2.5 boards/hr
High quality mode 12.4 m2/hr
4.1 boards /hr
Quality mode 23 m2/hr
8 boards/hr
Draft mode/express mode 42.3 m2/hr
14.2 boards/hr
System Specifications One-half Cmyk Speeds
Ultra quality mode + white 3.7 sqm/hr
High quality mode + white 6 sqm/hr
2 boards/hr
Quality + white 11.5 sqm
3.8 boards/hr
Resolution
  300 x 300 dpi
8 levels of grayscale
  600 x 600 dpi
4 & 8 levels of grayscale
  900 x 900 dpi
4 & 8 levels of grayscale
  1200 x 600 dpi
8 levels of grayscale
Controller
  EFI Fiery® XF RIP

  • The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
  • Some of the product illustrations contain optional accessories.
  • Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
  • Konica Minolta does not warrant that all specifications mentioned will be error-free.
  • Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
  • All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Get the product brochure now to have all information at hand.

EFI H1625LED brochure
